Número de pieza:
m24558-3-528
NSN
Número de acciones nacionales:
TXT
Descripción:
Terminal Box
Código de nombre del artículo:
00452
MRC:
The specific commercial rating which classes the item as to what degree the item will withstand environmental elements and/or hazardous locations.ABFE
Hazardous Locations/environmental Protection:
Submersible-nema type 6
MRC:
An overall measurement between specified points of an item,in distinction from height.ABFY
Overall Depth:
3.500 inches
MRC:
The length of a straight line which passes through the center of a circular figure or body,and terminates at the outside circumference.ABKV
Outside Diameter:
5.688 inches
MRC:
A measurement of the amount of turning necessary to bring one half into coincidence with another,expressed in degrees.ABVJ
Angle Between Centerlines Of Mounting Holes In Deg:
120.0
MRC:
The length of a straight line which passes through the center of an unthreaded mounting hole,and terminates at the circumference.AEBV
Unthreaded Mounting Hole Diameter:
0.406 inches
MRC:
A designation of the standard mounting facility arrangement provided.AESL
Standard Mounting Pattern Designator:
Bolt circle
MRC:
The length of a straight line which passes through the center of a mounting bolt circle,and terminates at the circumference.AFFL
Mounting Bolt Circle Diameter:
5.625 inches
MRC:
The means of attaching the item.AXGY
Mounting Method:
Bracket with hole
MRC:
Indicates the type and number of terminals for providing electrical connection.CCFF
Terminal Type And Quantity:
10 threaded stud
MRC:
The chemical compound or mechanical mixture properties of which the item is fabricated.MATT
Material:
Copper alloy
MRC:
The style designation indicating the configuration that most nearly corresponds to the appearance of the item.STYL
Style Designator:
Round surface mounting
